Scrolling Cards

Scrolling Cards

A dynamic, scroll-triggered component that creates an engaging card reveal animation sequence

Scroll to animate

Card 1

Reach fot the stars

Card image

Card 2

Reach fot the stars

Card image

Card 3

Reach fot the stars

Card image

Card 4

Reach fot the stars

Card image

Card 5

Reach fot the stars

Card image

Install the following dependencies:

pnpm add gsap

Make a file for cn function and match the import afterwards

import clsx, { ClassValue } from "clsx"
import { twMerge } from "tailwind-merge"
export const cn = (...classes: ClassValue[]) => twMerge(clsx(...classes))

Make a file and copy paste this code in a file with name scrolling-cards.tsx

"use client"
import { ReactElement, RefObject, useEffect, useRef, useState } from "react"
import { useGSAP } from "@gsap/react"
import ScrollTrigger from "gsap/ScrollTrigger"
import gsap from "gsap"

gsap.registerPlugin(ScrollTrigger)

interface CardSliderProps {
  cards: {
    card: ReactElement
    rotate: number
    transformOrigin?: string
  }[]
  cardWidth: number
  top?: number
  left?: number
  /**
   * Should be multiple of 100 eg. 100,200....
   */
  animationLength?: number
  scrollerRef?: RefObject<HTMLElement>
}

function ScrollingCards({
  cards,
  cardWidth,
  top = 45,
  left = 20,
  animationLength = 300,
  scrollerRef,
}: CardSliderProps) {
  const sectionRef = useRef<HTMLElement>(null)
  const cardsRef = useRef<HTMLDivElement[]>([])

  useGSAP(() => {
    if (!sectionRef.current || !cardsRef.current) return

    const unitLeftDis = (50 - left) / cards.length
    // Set initial position for all cards (below viewport)
    gsap.set(cardsRef.current, {
      top: window.innerHeight + 300,
      rotate: (i) => `${cards[i].rotate}deg`,
    })
    const innerTl = gsap.timeline({
      scrollTrigger: {
        trigger: sectionRef.current,
        start: "center center", // Start when section center hits viewport center
        end: `+=${animationLength}%`, // End after scrolling 300% of section height
        scrub: true, // Smooth scrubbing effect
        markers: false, // Set to
      },
    })
    // Create timeline for sequential animation
    const tl = gsap.timeline({
      scrollTrigger: {
        trigger: sectionRef.current,
        start: "center center", // Start when section center hits viewport center
        end: "+=300%", // End after scrolling 300% of section height
        pin: true, // Pin the section while animation plays
        pinSpacing: true,
        scrub: 1, // Smooth scrubbing effect

        markers: false,

        onUpdate: (self) => {
          const direction = self.direction
          const topCards = cardsRef.current.filter((card) => {
            if (
              card.offsetTop /
                (scrollerRef?.current?.getBoundingClientRect().height ||
                  window.innerHeight) <=
              top / 100
            )
              return true
            else return false
          })

          if (direction == 1) {
            innerTl.clear()
            innerTl.to(
              topCards,
              {
                left: (i) => {
                  return `${i * unitLeftDis + left}%`
                },
              },
              "<"
            )
          } else {
            innerTl.clear()
            innerTl.to(topCards, {
              left: "50%",
            })
          }
        },
      },
    })

    // Add each card to the timeline with sequential animation
    cardsRef.current.forEach((card) => {
      if (!card) return

      tl.to(
        card,
        {
          top: `${top}%`,
          ease: "none",
        },
        ">"
      ) // Stagger the animations
    })
  }, [cards, cardsRef.current])

  return (
    <section
      ref={sectionRef}
      className="h-screen relative flex items-center justify-center overflow-hidden"
    >
      {cards.map((item, index) => (
        <div
          key={index}
          ref={(el) => {
            if (el) cardsRef.current[index] = el
          }}
          style={{
            rotate: `${item.rotate}deg`,
            transformOrigin: `${
              item.transformOrigin ?? `${index % 2 === 0 ? "left" : "right"}`
            }`,
            width: `${cardWidth}px`,
            position: "absolute",
          }}
          className="transition-all  -translate-x-1/2 -translate-y-1/2 left-1/2  top-full"
        >
          {item.card}
        </div>
      ))}
    </section>
  )
}

function SnappingScrollingCards({
  cards,
  cardWidth,
  top = 35,
  left = 30,
  animationLength = 400,
  scrollerRef,
}: CardSliderProps) {
  const sectionRef = useRef<HTMLElement>(null)
  const cardsRef = useRef<HTMLDivElement[]>([])

  useGSAP(() => {
    if (!sectionRef.current || cardsRef.current.some((ref) => !ref)) return

    const unitLeftDis = (50 - left) / (cards.length - 1 || 1)

    // Calculate maximum rotation to adjust starting position
    const maxRotation = Math.max(...cards.map((card) => Math.abs(card.rotate)))
    const extraPadding = maxRotation * 2 // Add extra padding based on rotation

    // Reset all cards to initial position - move them further down to account for rotation
    gsap.set(cardsRef.current, {
      top: window.innerHeight + 300 + extraPadding,
      left: "50%",
      rotate: (i) => `${cards[i]?.rotate || 0}deg`,
      opacity: 0, // Start with opacity 0
      clearProps: "none", // Clear any previously set props
    })

    // Create main scroll trigger
    const st = ScrollTrigger.create({
      trigger: sectionRef.current,
      start: "center center",
      end: `+=${animationLength}%`,
      pin: true,
      scrub: 1,
      onUpdate: (self) => {
        // Calculate current scroll progress (0-1)
        const progress = self.progress

        // Total scroll is divided into sections:
        // - First 70% of scroll brings cards up sequentially
        // - Remaining 30% ensures all cards reach final horizontal position

        const verticalSection = 0.7 // 70% of scroll dedicated to vertical movement

        cardsRef.current.forEach((card, i) => {
          if (!card) return

          // Calculate when this card should start its vertical animation
          // (distributed evenly across the first 70% of scroll)
          const cardStartPoint = (i / cards.length) * verticalSection

          // Calculate progress of this card's animation sequence (0-1)
          let cardProgress =
            (progress - cardStartPoint) / (verticalSection / cards.length)
          cardProgress = Math.max(0, Math.min(1, cardProgress))

          // Calculate vertical position
          const verticalProgress = Math.min(1, cardProgress * 2) // Complete vertical movement in first half of card's sequence
          const startY = window.innerHeight + 300 + extraPadding
          const endY = (window.innerHeight * top) / 100
          const topPosition = startY - (startY - endY) * verticalProgress

          // Calculate horizontal position (starts when vertical is halfway done)
          let horizontalProgress = 0
          if (cardProgress > 0.5) {
            // Map 0.5-1 to 0-1 for horizontal animation
            horizontalProgress = (cardProgress - 0.5) * 2

            // Use eased progress based on overall scroll progress to ensure all cards finish together
            // When overall progress reaches 1, all cards should be at their final position
            const masterProgress = Math.min(1, progress / 1)
            horizontalProgress = Math.min(horizontalProgress, masterProgress)
          }

          // Calculate final left position
          const leftPos =
            50 - (50 - (left + i * unitLeftDis)) * horizontalProgress

          // Apply transforms directly
          gsap.set(card, {
            top: topPosition,
            left: `${leftPos}%`,
            opacity: cardProgress > 0 ? 1 : 0, // Fade in when animation starts
          })
        })
      },
    })

    return () => {
      st.kill()
    }
  }, [cards, cardWidth, top, left])

  return (
    <section
      ref={sectionRef}
      className="h-screen relative flex items-center justify-center overflow-hidden"
    >
      {cards.map((item, index) => (
        <div
          key={index}
          ref={(el) => {
            if (el) cardsRef.current[index] = el
          }}
          style={{
            rotate: `${item.rotate}deg`,
            transformOrigin:
              item.transformOrigin || (index % 2 === 0 ? "left" : "right"),
            width: `${cardWidth}px`,
            position: "absolute",
          }}
          className="transition-all -translate-x-1/2 -translate-y-1/2"
        >
          {item.card}
        </div>
      ))}
    </section>
  )
}
export { ScrollingCards, SnappingScrollingCards }

Usage

Scrolling Cards With Snapping Effect

Scroll to animate

Card 1

Reach fot the stars

Card image

Card 2

Reach fot the stars

Card image

Card 3

Reach fot the stars

Card image

Card 4

Reach fot the stars

Card image

Card 5

Reach fot the stars

Card image

Props

NameTypeDescription
cards*{ card: ReactElement; rotate: number; transformOrigin?: string }[]Array of card objects, each containing a React element, rotation angle, and optional transform origin.
cardWidth*numberThe width of each card in pixels.
topnumberThe top position of the card slider. Optional.
leftnumberThe left position of the card slider. Optional.
animationLengthnumberDuration of the animation in milliseconds. Should be a multiple of 100. Default is 100. Optional.
scrollerRefRefObject<HTMLElement>A reference to the scrolling container element. Optional.

Note: Props marked with * are required.
